Smart POWER 3600W air conditioner
The SMART POWER EZA rooftop air conditioner is designed to offer maximum performance with minimum energy consumption. Equipped with Inverter compression technology, it provides intelligent temperature management while being one of the quietest on the market. Reversible hot/cold and running on the more environmentally friendly R32 refrigerant, it is ideal for year-round use, whatever the weather.
Inverter technology: power and energy savings
Unlike conventional air conditioners, Smart power EZA uses an Inverter compressor that continuously regulates its power, avoiding unwanted stops and restarts. This meansA 50% reduction in energy consumption
Smooth start-up without current peaks (<1A)
Operation on electrical terminals from 4A or by means of a 1000W inverter
With its two available power ratings (2700W and 3600W), it can be adapted to different air-conditioning needs, guaranteeing maximum efficiency with low energy consumption.
An ultra-quiet air conditioner for absolute Comfort
Thanks to its Silentbloc compressor, SMART POWER EZA is one of the quietest air conditioners on the market, with a sound level between 43 and 54 dB. Ideal to enjoy quiet nights in your converted motorhome or van.
Its extra-flat diffuser is equipped with LED ambient lighting and an LCD display, adding a modern and elegant touch to your interior. It can be installed in the central skylight or in the bedroom, whichever you prefer.
Reversible heating/cooling: a perfect climate in any season
SMART POWER EZA has a reversible heat pump, so it can be used in both summer and winter:
Cooling mode: effective between +18°C and +46°C
Heat mode: effective between -5°C and +24°C
Thanks to this technology, it can maintain a comfortable temperature even in extreme conditions. Its adjustable air flow (from 225 to 340 m³/h) allows you to adjust the ventilation for personalized thermal comfort.
A connected air conditioner for simplified management
With its integrated WiFi connection, you can control your air conditioner directly from your smartphone or tablet via a dedicated application. You can :
Adjust the temperature and air flow rate
Activate the timer and turbo mode
Manage LED lighting
Adjust settings remotely for optimal comfort
Finally, SMART POWER EZA uses R32 refrigerant, which is 2 times more environmentally friendly than R134A and 4 times more environmentally friendly than R410A, reducing the environmental impact while ensuring excellent energy efficiency.
Type : Rooftop air conditioner
Technology : Silentbloc Inverter compressor
Refrigerant : R32, low environmental impact
Reversible cool/heat : Yes, integrated heat pump
Available capacities : 2700W / 3600W
Heating capacity : 2500W / 8530 Btu/h
Soft start : No peak current (<1A)
Operating temperature ranges :
Hot: -5°C to +24°C
Cool: +18°C to +46°C (+18°F to +46°F)
Noise level: 43-54 dBA
Air flow rate: 225 - 340 m³/h
Diffuser: Extra-flat with 2 outlets with LCD display and LED illumination
Mounting: 40 x 40 cm recess mounting
Maximum operating angle: 8%
Color: White
Dimensions:
Outer unit: 1077 x 720 x 283 mm
Diffuser: 610 x 485 x 49 mm
Weight :
Outdoor unit: 29.5 kg
Diffuser: 2.7 kg
Degree of protection: IPX4
Certifications: CE, environmental compatibility R10
Included accessories: Multi-function remote control, cooling unit and diffuser, stainless steel screws and bolts
Warranty: 24 months
Cooling power: 3600W / 12243Btu/h
SEER: 3.27
Cooling consumption:
Turbo mode: 1350W / 5.8A
Normal mode: 1100W / 4.7A
Regulation mode: 600W / 2.6A
SCOP: 3.58
Thermal consumption:
Turbo mode: 1000W / 4.3A
Normal mode: 950W / 3.5A
Regulation mode: 450W / 2.1A
Recommended vehicle size: 8-10 meters
Other characteristics
Refrigerant: R32
Reversible cooling / heating (heat pump) : Yes
Cooling power : 3600 W
Cooling capacity in Btu/h : 12283
SEER : 3,27
Cooling consumption in watts/amperes : TURBO MODE (max.): 1350 W / 5,8 A NORMAL MODE: 1100 W / 4,7 A REGULATING MODE (min.): 600 W / 2,6 A
Heating capacity : 2500 W
Heating capacity in Btu/h : 8530
SCOP : 3,58
Hot consumption in watts/amperes : TURBO MODE (max.): 1000W / 4,3A NORMAL MODE: 950W / 3,5A REGULATING MODE (min.): 450W / 2,1A
Peak current at start-up : NONE / soft start (< 1A) A
Operating Temperature : Hot -5° to +24° Cold +18° to +46
Noise level (dBA) : 43-54
Min/max air flow rate (m3/h) : 225 - 340 m³/h
Diffuser : Extra-slim 2 outlets
Lighting : Ambient - LED
Mounting in opening : 40 x 40 cm
Temperature ranges : 16 to 30 °C
Maximum operating gradient : 8 %
Recommended for vehicles : > 8 m
Dimensions of the bare outdoor unit (L x W x H) : 1077 x 720 x 283 mm
Diffuser dimensions (L x W x H) : 610 x 485 x 49 mm
Net weight : 32,2 kg
Supplied with : Multi-function remote control, cooling unit and diffuser, stainless steel screws and bolts
Protection indicator : IPX4
Color : White
Model : G4 3600W
IP protection degree : IPX4
Sound level : 43-54
Type : Roof air conditioner
